Product Description
Description
The Edwards 10 Ton Bender provides great flexibility to your shop. With over 300 dies available to bend pipe, tube, or square tube up to 180 deg , this Bender is a must have for any fabrication shop. Able to operate either Horizontally or Vertically depending on your project and with a heavy-duty rolling base, you can move the Bender out of the way when your project is complete. This Bender package includes a Portable Power Unit and is ready to PLUG IN & POWER UP.
Features
- 20' quick-connect hoses for simple "plug & play" operation
- Bend a wide variety of round or square tube and pipe up to 180 deg s
- Built-in storage on the frame keeps your Bender Dies conveniently close
- Easy-to-use hand/jog controls with integrated E-Stop
- Heavy-duty rolling stand allows you to move the Radius Roller around as needed
- Horizontal or Vertical operation provides the user flexibility
- Integrated proximity sensor and degree wheel ensure you make the right bend every time
- Over 300 standard dies available to handle your bending needs
- Requires an Edwards Ironworker with PowerLink System or a Portable Power Unit to operate (included)
Specifications
- Bend Capacity: 180.0000
- Country of Origin: US
- Cylinder (In): 1-3/4" Ram
- Gross Weight (Lbs): 1000.0000
- Height: 100.000
- Hydraulics (GPM): 3-1/2
- Length: 66.000
- Max. Bend (Deg.): 180
- Net Weight (Lbs.): 1000.0000
- Overall Dimensions (L x W x H) (In.): 66 x 93 x 100
- Pipe Capacity (In.): 2 (ID) Sch 40
- Product Dimensions (In.): 40-1/2 x 36-1/2 x 42
- Rating (Tons): 10.0000
- Round Pipe Sch. 40 Capacity (In.): 2
- Round Tube Capacity (In.): 2-1/2
- Square Tube Capacity (In.): 2 (OD) .25
- Stroke (In.): 14
- Tube Capacity (In.): 2-1/2 (OD) .095
- Valve Pressure (PSI): 2750.0000
- Warranty: 1 Year
- Weight: 980.000
- Width: 93.000
Product Videos
Custom Field
Item Type POWRTOOL
Product Type 10 Ton Bender
Country of Origin US
Length 66 in
Width 93 in
