Product Description
The GEARWRENCH family of torque wrenches & torque products offer the latest innovations in torque measurement. Included in the line are micrometer, tire shop, beam and electronic torque wrenches, as well as, torque multipliers. The micrometer wrenches are available in fixed head and flex head. The fixed head line offers wrenches in 1/4" to 3/4" drives. The flex head wrenches are available in 3/8" and 1/2" drives. The tire shop wrenches feature a rugged tire tread rubber cover on the head intended to specifically be used for checking wheel lug nuts and are available in 3/8" and 1/2" drives. The electronic torque wrenches ensure a more precise fastener torque level and are available in a 3/8" and 1/2" drives. The GEARWRENCH line of torque products allow the user to complete any job where accurate torque is required.
Features
- Bend pointer to zero before use
- Directly measure a variety of torque values when tightening fasteners
- Palm-fit handle pivots on the beam to maintain a constant distance from the drive point for precise measurement
- Scale includes both SAE and metric sizes and provides a readout in ft-lb, Nm, and in-lb
- Torque accuracy of +/-7% when measuring torque in a clockwise or counterclockwise direction
Specifications
- Alt Scale Increments: 12 Nm
- Certified: No
- Country of Origin: TW
- Coupon Headline: Deflecting Beam Torque Wrenches
- Drive Tang Size: 3/8 in
- Finish: Full Polish Chrome
- Flexible: No
- Foreign Trade Code: 8466100175
- Head Length: 0.81 in
- Head Thickness: 1.325 in
- Head Thickness Less Tang: 0.875 in
- Head Width: 0.812 in
- Knurled: No
- Long Description: 3/8" Drive Beam Torque Wrench 0-800 in/lbs.
- Material: Alloy Steel
- Maximum Torque (Alt Scale): 90 Nm
- Maximum Torque (Primary Scale): 800 in/lb
- Minimum Torque (Alt Scale): 0 Nm
- Minimum Torque (Primary Scale): 0 in/lb
- Overall Height: 1.75 in
- Overall Length: 16 in
- Overall Width: 2 in
- Packaging: Boxed
- Primary Scale Increments: 50 in/lb
- Set: No
- Table Description: 3/8" Drive Beam Torque Wrench 0-800 in/lbs
- Tether Ready: No
- Torque Accuracy (20-100% of Full Range): +/- 7% Clockwise
- Type 1: Beam
- Warranty: Full Lifetime
- Weight: 1.535 lbs
