Product Description
The GEARWRENCH family of torque wrenches & torque products offer the latest innovations in torque measurement. Included in the line are micrometer, tire shop, beam and electronic torque wrenches, as well as, torque multipliers. The micrometer wrenches are available in fixed head and flex head. The fixed head line offers wrenches in 1/4" to 3/4" drives. The flex head wrenches are available in 3/8" and 1/2" drives. The tire shop wrenches feature a rugged tire tread rubber cover on the head intended to specifically be used for checking wheel lug nuts and are available in 3/8" and 1/2" drives. The electronic torque wrenches ensure a more precise fastener torque level and are available in a 3/8" and 1/2" drives. The GEARWRENCH line of torque products allow the user to complete any job where accurate torque is required.
Features
- 1 year limited warranty; calibration accuracy warrantied for 90 days
- Built-in angle of turn protractor displays the output angle, providing effective use on fasteners requiring a specific angle rotation after applied torque
- Built-in anti-backlash maintains the multipliers input torque, allowing the use of a ratcheting head torque wrench for more efficiency
- Input and output rotate in a matching direction, while the reaction arm moves in the opposite direction from the input/output force
- Internal planetary gear system provides strength and durability
- Low input torque is required and can easily be applied by one person
- Made in the USA
- Place an impact socket on the output square to attach to the fastener, then restrain the reaction bar against the equipment being serviced
- Square drive shears at 3% to 10% of overload torque to help protect against internal damage and permits easy replacement of the square drive
- Torque accuracy of +/- 5% CW between 20% and 100% of wrench capability
Specifications
- Angle of Turm Protractor: Yes
- Case Color: Black
- Certified: No
- Country of Origin: US
- Coupon Headline: 3,200 Foot Pound Reaction Bar Torque Multiplier
- Finish: Electroless Nickle
- Flexible: No
- Foreign Trade Code: 8466100175
- Gear Ratio: 20.2:1
- Head Length: 6.375 in
- Head Thickness: 6.5 in
- Head Width: 4.031 in
- Included Storage: Blow Mold Case
- Input Drive: 1/2 in
- Knurled: No
- Long Description: 3,200 Foot Pound Torque Multiplier
- Material: Steel
- Maximum Input Torque: 173 ft/lb
- Maximum Output Torque: 3200 ft/lb
- Output Drive: 1" Square Drive
- Overall Height: 6.5 in
- Overall Length: 20 in
- Overall Width: 4.1 in
- Packaging: Boxed
- Repair Kit: 64-852G
- Set: No
- Table Description: 3,200 Foot Pound Torque Multiplier
- Torque Accuracy (20-100% of Full Range): +/- 5% Clockwise
- Torque Ratio: 18.5:1
- Type 1: Multiplier
- Warranty: 90 Days Calibration/1 Year on Parts
- Weight: 22.320 lbs
