Product Description
Description
Unique split-tip design penetrates through steel faster. Resists walking or skidding, even on round surfaces. Balanced, double-flute construction requires less pressure, does the work for you. Designed and manufactured in USA.
Specifications
- Application: ''For punching metric size holes in mild steel, aluminum, fiberglass, and plastic.''
- Capacity Mild Steel: Max: 14 gauge (2.0 mm).
- Country of Origin: US
- Diameter: ''Actual hole size: 20.4 mm (0.803'''')''
- Draw Stud: ''Std. Draw Stud: 7212SP14 (3/8'''' X 3.82'''').''
- Draw Studs: ''Alt. Draw Stud (Long): 7212SP13 (3/8'''' x 4.69'''') - For use w/746 Hydraulic Ram.''
- Driver: ''Use with Greenlee Punch Drivers: LS50L - Battery-Powered Driver, or Hydraulic Drivers:10383 - QUICK DRAW(R) FLEX, 34288 - QUICK DRAW(R) STANDARD, 33786 - QUICK DRAW 90(R), OR 746 HYDRAULIC RAM & 767 PUMP.''
- Height: 3.750 in
- ISO: ISO-20
- Length: 3.750 in
- Material: Black Oxide Finish
- Minimum Pilot Hole: ''1/2'''' (12.7 mm)''
- Operation: Must be used with other SPEEDPUNCH(TM) System components.
- Type: Knockout Punches
- Weight: 0.15 lbs
- Width: 3.750 in
Product Videos
Custom Field
Item Type Other
Country of Origin US
Length 3.75 in
Width 3.75 in
Diameter ''Actual hole size:
Material Black Oxide Finish
