Product Description
Sold Per 1 Each GMP Fiber Optic Strand Lock Cable Block Product Information:This heavy duty fiber block is used for supporting a single fiber optic cable up to one inch diameter onto a maximum strand size of 3/8" (25mm) prior to lashing. Particularly recommended where a higher level of security is required such as crossing roadways or waterways. Always be certain to use enough blocks spaced close together to avoid any creation of cable sag
This block features the lever operated cam that locks the block in position while pulling, then automatically releases during lashing
The frame is constructed from a heat treated aluminum alloy
Oilite bearings on the sheave, and steel inserts on the underside of each strand hook allow the block to slide easily on strand for positioning
A removable pin keeps the cable from jumping out of the sheave. The pin is tethered to the block to prevent losing it
The frame hooks can accommodate strand from 1/4" to 3/8" (6-10mm) diameter Weight: 3 lbs. 12 oz. (1.7kg)
